Tianle eArc to RCA+SPDIF+HDMI Audio Converter - ARC & eARC Support, 24bit/192KHz Audio Sampling Rate, HD 5.1 & 7.1 Channels

Product Introduction: This product is designed to upgrade amplifiers or soundbars that do not support eARC function to be able to connect with TVs that support eARC function, so that they can obtain high-definition audio through the TV's eARC channel. It can also connect the audio signal of a TV that supports eARC to an amplifier or headphones through the fiber optic and analog stereo interfaces of this eARC audio converter. This eARC audio converter is also compatible with TVs that have ARC function. Product Specifications: Input interface: eARC/ARC HDMI output version: HDMI 1.4 HDMI output resolution: 720P (HDMI only transmits audio signals and no images) Output interface: HDMI1, fiber optic1, RCA2, 3.5mm1 Supported audio formats: PCM, AC3, DTS, DD+, DTS-HD Master audio, DOLBY True HD Power interface: DC5.5 Power voltage and power consumption: DC5V/300mA Enclosure material: Aluminum alloy Operating temperature: -10~+55℃ Storage temperature: -20~+60℃ Operating humidity: 1090%RH (non-condensing) Storage humidity: 595%RH (non-condensing) Product size: 906521 (mm) Weight: 90g Package Contents: 1xConverter 1xUSB power cable 1xUser manual

• Supported audio formats PCM.AC3,DTs,DD+, DTS-HD Master audio, DOLBY True HD
• Supports eARC and ARC inputs;HDMI, fiber optic, RCA, and 3.5mm headphone outputs (HDMI only transmits audio signals and no images)
• HDMI output supports up to HD 5.1 and HD 7.1 channels;Fiber optic interface supports up to 5.1 channels
• Supports transmission of 24bit/192KHz audio sampling rate
• RCA and 3.5mm headphone output volume can be controlled by TV remote control (CEC)
• Supports input audio channel indicator lights
